Introduction
1.1 Equipment requirements: The device can process many kinds of non-woven， paper-plastic and other raw material.
1.2 Equipment working principle: width folding→length cutting→length folding→output automatically→Product stacking, the whole line complete automatically.
1.3 Width of raw material≤ 2000mm
1.4 Cutting length can be adjusted between 500-3000mm, length error of ± 5 mm.
1.5 Length folding: one time half fold , two times half fold, three times half folded ,one third fold, one sixth fold
1.6 The machine adopts the cylinder to promote the material and tension control automatically, without manual operation
1.7 Touch screen control, enter the data can change the specs, easy to operate.
1.2 Equipment working principle: width folding→length cutting→length folding→output automatically→Product stacking, the whole line complete automatically.
1.3 Width of raw material≤ 2000mm
1.4 Cutting length can be adjusted between 500-3000mm, length error of ± 5 mm.
1.5 Length folding: one time half fold , two times half fold, three times half folded ,one third fold, one sixth fold
1.6 The machine adopts the cylinder to promote the material and tension control automatically, without manual operation
1.7 Touch screen control, enter the data can change the specs, easy to operate.
播放视频
Technical Parameter
2.1 Supply Voltage: 380V 50HZ
2.2 Power: 12KW
2.3.Weight: 4000kg
2.4.Speed: 0-70 m / min
2.5.Dimensions: 9000 * 2400 * 2000mm
2.6.machine color: silvery white
Equipment configuration list
3.1 Servo motor: Delta (Taiwan) 8sets
3.2 Gear motors: Yongkun (Taiwan) 1set
3.3 Motion Controller: Delta (Taiwan) 1 set
3.4 Touch screen: Delta (Taiwan) 1set
3.5 Low-voltage electrical: delixi
3.6 Air shaft: 1set
3.7 Cylinder: 1set
